ROSA
Description
Description
Product Description
◆ This product is an optical receiving component with a working rate of 155M, 1.25G, and 2.5G
◆ Using PIN-TIA diodes
◆ Chip information: PT: 155M, 1.25G, 2.5G PIN-TIA
◆ Remarks on product structure: LC/PC ferrule sleeve assembly, viscose structure
Features
◆ Using laser welding solution
◆ High optical isolation
◆ High sensitivity
◆ Working temperature: 0℃~75℃
◆ Pluggable LC ROSA
Product Standards
◆ Meets Telcordia GR-468 Reliability Test Standard
◆ RoHS 6-item compliant
◆ Meets ROHS (Restriction of Hazardous Substances) standards
◆ Meets GR-326 Connector Qualification Standards
Applications
◆ Remote communication
1.Absolute Maximum Ratings
2.Receiver Electro-Optical Characteristics (TC=25°C, Vcc=3.3V)
3.Dimension Outline
◆ This product is an optical receiving component with a working rate of 155M, 1.25G, and 2.5G
◆ Using PIN-TIA diodes
◆ Chip information: PT: 155M, 1.25G, 2.5G PIN-TIA
◆ Remarks on product structure: LC/PC ferrule sleeve assembly, viscose structure
Features
◆ Using laser welding solution
◆ High optical isolation
◆ High sensitivity
◆ Working temperature: 0℃~75℃
◆ Pluggable LC ROSA
Product Standards
◆ Meets Telcordia GR-468 Reliability Test Standard
◆ RoHS 6-item compliant
◆ Meets ROHS (Restriction of Hazardous Substances) standards
◆ Meets GR-326 Connector Qualification Standards
Applications
◆ Remote communication
1.Absolute Maximum Ratings
| Item | Symbol | Unit | Min | Max | Note |
| Storage Temperature | TSTG | ℃ | -40 | +85 | |
| Operating Temperature 7 | TOPR | ℃ | 0 | +75 | |
| Lead Soldering Temperature(Max10 sec) | TS | ℃ | --- | 260 |
2.Receiver Electro-Optical Characteristics (TC=25°C, Vcc=3.3V)
| Item | Symbol | Test Condition | Min. | Typ. | Max. | Unit |
| Supply Current | ICC | According to TO selection, the range will be different | --- | --- | --- | mA |
| Operation Wavelength | λ | 1270 | 1310 | 1610 | nm | |
| Saturation Power | PSAT | NRZ, λ=1310nm ，2.488 Gbps ，PRBS223-1，BER=10-10，ER=5dB | -7 | --- | --- | dBm |
| Sensitivity | Sen | BER=10^10 P @2.5G,ER=10dB,PRBS2^23-1 | -27 | dBm | ||
| Optical Return Loss | ORL | -- | --- | -20 | dB |
3.Dimension Outline
